colour: clear
length: 1.2m
bore as supplied min.: 6.4mm
shrink temperature: 90°C
temperature range : 125°C
radial shrinking ratio: >50%
longitudinal change: <5%
tensile strength: >10.4 MPa
ultimate elongation: >200 %
aging in circulating-air oven: 158.0±1.0°C, 168hrs
tensile strength: >7.3MPa
after aging:
ultimate elongation: >100%
volume resistivity: >1014 Ohm.cm
dielectric strength: >15 KV/mm
flammability: VW-1
concentricity: >65%
Heat-shrinkable tubing is universally applied for the insulation of connections or for the end-handling of electric wire, for the insulation of soldered points on resistors and capacitors, for the identification and encapsulation of electric wire, for the corrosion-proofing of metallic rods or tubes and for the protection of antennas. Heat-shrinkable tubes are used for the corrosion-proof and waterproof connection of fibre optic cable. Halogen-free, flexible, flame-retardant heat-shrinkable tubing. Free of Pb,Cd, Hg,Cr+6, PBB and PBDE. Can be used in any enclosed area where a flame-retardant, halogen-free environment is required, such as the uderground, skyscraper, mass transit vehicles and ships. UL recognized at 600V. F mark.
