| Range Selection | manual |
| Display | 31/2 (1999 counts), a digit is 15 mm high |
| DC voltage | 200 mV/2/20/200 V ±0.5%, 1000 V ±0.8% |
| AC voltage | 200 mV/2/20/200 V ±0.8%, 750 V ±1.2% |
| DC current | 200µA/2/20/200 mA ±1.2%, 10 A ±2.0% |
| AC current | 2/20/200 mA/10 A |
| Resistance | 200 Ω /2/20/200 Ω /2M Ω ±0.8/%, 20 M Ω |
| Diode / transistor hFE test | Yes |
| Data Hold function | Yes |
| Charge battery indication | Yes |
| Overload indication “1” | Yes |
| Power source | 1.5 V (AAA) x 3 |
| Dimensions | 158 × 74 × 31 mm |
Features:
- AC / DC current measurement max 10A
- DC 1000VDC voltage measurement;
- 750VAC AC voltage measurement
- resistance measurement
- continuity test
- hold function
General Characteristics:
•Data Hold
•Continuity measurement with buzzer
•Diode measurement
•Transistor measurement
•Dimensions (HxWxD)mm: 156 x 71 x 32
