- Module nature: non-isolated BUCK
- Input voltage: DC12V (wide voltage 8~22V), DC 12V24V (wide voltage 8~40V)
- Output voltage: DC 5V
- Output current: 1A~40A optional
- Output power: 5W~200W
- Installation cable length: 13-14cm
- Ripple: (1A-30A) 40MV, 40A 170MV
- Low power consumption: (1A-3A) 1.4MA, (5A-10A) 11MA, (10A-30A) 15MA, 40A 70MA
- Protection function: over current / over voltage / over temperature / short circuit protection
- Waterproof rating: IP67
- Scope of application: all kinds of vehicle system modification, routers, ADSL modems, switches, LED digital photo frames, electronic refrigerators, portable DVDs, audios, security systems, portable tools, printers, network equipment, control equipment and other voltage parameters Industrial equipment
– Reminder: there is no reverse connection protection for the input, please connect carefully, and the output voltage of the power supply cannot be directly used to charge the battery
