Parameter Value
Model: AQ-4511-RS4
Camera:Image Sensor: 1/2.7” 5MP Progressive Scan CMOS
Resolution: 2590*2048
Image System: PAL/NTSC
Light ON: 0.1 lux @ (F2.0, AGC ON)
Lens: 2.8mm
LEDs: 12 PCS SMD LED
Cable: DIP switch
SNR: >52dB（AGC off）
Full color distance: 15m
Video Frame Rate: 5MP@20fps,5MP@12.5fps,”>5MP@20fps,5MP@12.5fps
Video Output: TVI/AHD/CVI/CVBS
Menu
D&N: Support ICR EXT/Auto / Color/ BW
DNR: Support 2D NR
WDR
DWDR
White Balance: ATW / MWB
BLC: Support
Image set: contrast、sharpness、saturate、3DNR、2DNR、DWDR
Language: English, Chinese
General
Power Supply
12VDC ± 10 %;
Operating Conditions
(-20° C to 60° C), Humidity 90% or less (non-condensing)
Protection level
IP66
Dimensions
140mm*63mm*63mm
Shell Material
Metal
Power Consumption
Max. 3W
(Max.3W with IR cut filter on)
