Demodulator:
- Compatible with DVB-T /T2 (ETSI EN 300 744)
- RF Input Frequency: VHF: 177.143~213.143 MHz / UHF: 473.143~803.143 MHz
- Bandwidth: Accepts low IF inputs at 1.7, 5, 6, 7, 8 MHz
- Demodulation: Supports all constellations (QPSK / 16-QAM / 64-QAM / DQPSK / 256-QAM)
- Supports all guard intervals (1/128 to 1/4)
- Supports all FFT modes from 1k ~ 32k
- Supports all coding rates (1/2, 3/5, 2/3, 3/4, 4/5, 5/6, 2/5, 1/3)
- Transmit Diversity support (MISO)
- Supports all scattered pilot patterns (PP1 to PP8)
- Supports rotated and non-rotated constellations
- Supports single and multiple PLPs
- Fully digital demodulation and timing recovery for frequency and clock monitoring
- Automatic co-channel and adjacent channel interference suppression
- Impulse-Noise suppression
- Outside GI enhancement
- Lock time improvement
Microprocessor:
- High-Performance MIPS34Kf CPU with hardware floating point support
- Maximum performance: 1200 DMIPS
- Memory Management Unit to support Linux
Transport Stream Processor:
- Supports playback from live stream or DRAM
- Supports time-shifting and PVR function
- 64 PID filters and 64 section filters
Video Decoder:
- Multi-standard MPEG-1/2/4 video decoder
- Supports resolution up to 1920×1080@60fps
- Supports HEVC/H.265 decoding
- Supports maximum bitrate up to 50 Mbps
Audio Decoder:
- Multi-standard audio sample rate conversion (SRC)
- Supports decoding of digital audio: MPEG-1, MPEG2 (Layer I/II), MP3, AC-3 (Dolby Digital), E-AC-3 (Dolby Plus), AAC-LC 5.1 Channel, HE-AAC v1/v2, WMA, RA8-LBR
- Supports AC-3 stream output via SPDIF
Dimensions:
- Product Dimensions: 168 x 100 x 38 mm
- Packaging per piece: 1 pc
- Package Dimensions (LxWxH): 185 x 155 x 50 mm
- Gross Package Weight: 0.5 KG
