System:
Main Processor: Embedded Processor
Operating System: Embedded LINUX
Video & Audio:
Video input: 8 channel AHD
Audio input: 4 channel RCA
Audio output: 1 channel RCA
Two way talk
Display Video output: 1*HDMI, 1*VGA
Display Split: 1/4,1/8,1/9
Resolution: 1280×720
Recording: Video/Audio Compression
H.264 Main profile/G.711
Resolution: 1080N
Record Rate (Main stream): 8ch 720P real time recording
Recording mode: Manual/Alarm/Motion
Detection/Schedule: Motion detection
Detection zone:192(16*12)
Playback & Backup:
Playback: 1ch 720P real time playback+3ch 720P not real time playback
Backup Mode: Network/USB 2.0 Devices
Network: Ethernet RJ45 10M/100M
Network Functions: HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE,DDNS, FTP
Network Monitoring: Web viewer, CMS, Android & iPhone application
Storage: Internal HDD (2 SATA HDD, up to 4TB per HDD)(not incl.)
Auxiliary Interface:
Alarm input: 4
Alarm output: 0
PTZ control: through RS485 with multi-protocol
USB interface: 2
Power Supply: DC12V 4A
Power Consumption: <10W(without hard disk)
Operation Condition: 0℃-+55℃/10%－90%
Dimensions: 326(W)*243(D)*52(H)mm
With Remote Control
Possible connections of analogue and IP cameras on this Hybrid DVR:
8x AHDN/1080N
4x AHDH/1080P
4x AHDN/1080N
2x AHDH/1080P + 2x IP 1080P
8x IP 1080P
8x IP 960P
8x IP 3M
Recording: 8 channel 720P at real time
Reproducion: 4 channel 720P (1CH at real time 720P + 3ch not real time)
Support: ONVIF 2.0. & P2P Cloud
Support: HDMI/VGA, PTZ, 3G/WiFi
Smartphone & multi-browser & remote control support
USB mouse (incl.)
2xSATA MAX 4TB
