System
Main Processor: Embedded Processor
Operating System: Embedded LINUX
Video & Audio:
Video input: 4 channel AHD
Audio input: 4 channel RCA
Audio output: 1 channel RCA
Two way talk
Display Video output: 1*HDMI, 1*VGA
Display Split: 1/4
Resolution: 1280×720
Recording:
Video/Audio Compression: H.264 Main profile/G.711
Resolution: 1080N
Record Rate (Main stream): 4ch 1080N real time recording
Recording mode: Manual/Alarm/Motion
Detection/Schedule: Motion detection
Detection zone:192(16*12)
Playback & Backup:
Playback: 1ch 1080N real time playback+3ch 1080N not real time playback
Backup Mode: Network/USB 2.0 Devices
Network: Ethernet RJ45 10M/100M
Network Functions: HTTP, IPv4/IPv6, TCP/IP, UPNP, RTSP, UDP, SMTP, NTP, DHCP, DNS, PPPOE,DDNS, FTP
Network Monitoring: Web viewer, CMS, Android & iPhone application
Storage: Internal HDD (1 SATA HDD, up to 4TB per HDD)
PTZ control: through RS485 with multi-protocol
USB interface: x 2
Power Supply: DC12V 2A
Power Consumption: <10W(without hard disk)
Operation Condition: 0℃-+55℃/10%－90%
Dimension: 250(W)x210(D)x45(H)
DVR: 4 Channel 1080N at real time.
Reproduction: 4 channels 1080N (1CH at real time + 3ch not at real time)
Support: ONVIF 2.0. and P2P Cloud
Supported: HDMI/VGA, PTZ, 3G/WiFi
Smartphone & multi-browser, control
USB mouse (inc.)
2xSATA MAX 4TB (not incl.)
