Technical specifications:
Video:
Frequency response:DC to 5Mhz
ATTENUATION:0.5dB typ
Common-mode/Differential-mode rejection 15KHz to 5MHz 60dB typ
Impedance: Coax, male BNC:75 ohms / UTP, Screwless terminal blocks:100 ohms
Power: No external power required
Environmental:
Temperature -20 to +75 degrees
Humidity(non-condensing) 0 to 95 percent
Transient Immunity: per ANSI/IEEE 587 C62.41
Wire Type: Network wiring:one unshielded twisted-pair 24-16 AWG (0,5-1.31 mm) / Category type: 5 or Higher
Impedance:100+-20 ohms
DC Loop Resistance (24 AWG) 52 ohms per 1,000ft, (18 ohms per 100m)
Differential Capacitance: 19 pf / ft max (62pF/m max) Mechanical: Size: 50mm x 22mm x 16.5mm / Weight: 35g
The super anti-interference video transceiver is a passive (non-amplified) device that allows the transmission of real-time monochrome or color video over Unshielded twisted-pair (UTP) telephone wire. Baseband (composite) signals of any type are supported
Transmission distances of color signal up to 1,000ft(300m)
Exceptional interference rejection. Built-in unique LRC passive anti-interference filter circuit,effectively restrain common-mode noise
Male BNC allows connection directly to the camera or DVR
Reliable Screwless UTP terminal connection
No power required
Built-in transient protection
